TRUMPETER

1:35 M901 LAUNCHING STATION & AN/MPQ-53 RADAR SET

SKU: MBA001562WSD

RADAR SET OF 10



This is a Scale Model Kit, Paint and Glue are not included.



The MIM-104 Patriot is a modern US medium-range surface-to-air missile system. The first prototypes of the MIM-104 Patriot missile appeared in the late 1960s, and entered the line in the US armed forces in 1981. The latest versions of the MIM-104 missiles can engage air targets at an altitude of up to 25 km and at a distance of up to 160 km, and can carry a warhead weighing up to 90 kilograms. In the US Army, the Patriot system is often built on a wheeled chassis - most often the M983 Oshkosh trucks.

The MIM-104 Patriot system was developed by Raytheon to replace the MIM-23 Hawk and MIM-14 Nike Hercules missiles. Work on it began in 1961, and the trial - successful - firing dates back to 1969. However, shortly thereafter, the US armed forces changed the requirements for the system and decided that it would use the Track-via-Missile (TVM) system, which assumed the self-collection of information about the target by a missile already fired. This requirement significantly increased the level of difficulty of the entire undertaking and significantly extended the work. It was not until the end of the 1970s that it was possible to meet the high demands of the American armed forces, and from 1981 the MIM-104 Patriot system began to enter the line. The Patriot system was originally designed as a theater air defense system to fight enemy aircraft, but since the early 1990s, with the introduction of the MIM-104C missile and the use of much more advanced guidance systems and radars, the system has achieved the ability to combat enemy ballistic missiles short and medium range. The system was used in combat primarily in Operation Desert Storm in 1990-1991. The operators of the Patriot system, in addition to the US armed forces, are also, among others: Greece, the Netherlands, Israel, Japan and Germany. The system is also offered to Poland as part of the Wisła program.

The AN / MPQ-53 is a US-made mobile radar from the Cold War and modern times. The radar is most often transported on a wheeled chassis. The radar antenna is phase-scanned. passive electronically scanned array) and uses approx. 5,200 active elements. The wavelength of the radar is 3.5 to 7.5 centimeters. According to official data The AN / MPQ-53 is able to track 90 to 125 targets simultaneously and simultaneously guide up to 9 missiles. The AN / MPQ-53 radar was developed by Raytheon for the MIM-104 Patriot system and is the basic radar of this system. The system's combat management center, called AN / MSQ-104, is responsible for its control and information processing, which in turn consists of such elements as: Weapons Control Computer), Data Link Terminal or UHF communication system. It is assumed that the radar AN / MPQ-53 is very resistant to enemy generated interference. Official data say that the presented radar is able to detect a target at an altitude of up to 100 meters from a distance of 35-50 km, while a target flying above 1000 meters - from a distance of 170 kilometers. It is worth adding that the AN / MPQ-53 radar is able to work in a network created by other radars of this type and freely transfer information between them.
